DIN 2633 PN16 Weld Neck Flanges Manufacturer and Supplier In Manila, Philippines

Ting Flanges, a reputable manufacturer and supplier located in Manila, Philippines, has built a solid reputation for crafting top-notch DIN 2633 PN16 Weld Neck Flanges that adhere to international engineering standards. These flanges are specifically designed for medium-pressure piping systems, offering remarkable strength, secure sealing, and impressive durability. Utilizing cutting-edge technology and high-quality materials, Ting Flanges guarantees that each product provides excellent corrosion resistance, precision, and reliability. They find extensive application in industries like oil and gas, power generation, petrochemical, and water treatment, where they are engineered to perform effectively even in challenging operational conditions around the globe.

DIN 2633 PN16 Standards Weld Neck Flanges in Manila, DIN 2633 PN16 Weld Neck Plate Flange in Cebu City, Raised Face DIN 2633 PN16 WNRF Flanges in Puerto Princesa, Stainless Steel DIN 2633 PN16 Weld Neck Flanges in Baguio, DIN 2633 PN16 Welding Neck Pipe Flange in Davao City, Best Price of DIN 2633 PN16 Weld Neck Flange Manufacturer in Philippines.

Stainless Steel DIN 2633 PN16 Weld Neck Flanges

Alloy Steel DIN 2633 PN16 Weld Neck Flanges

Alloy 20 DIN 2633 PN16 Weld Neck Flanges

Typically, DIN 2633 PN16 Weld Neck Flanges are constructed from premium stainless steel, carbon steel, or alloy steel. They boast outstanding mechanical properties, with tensile strength ranging from 400 to 600 MPa and yield strength between 200 and 350 MPa. These flanges are designed to resist corrosion, temperature changes, and pressure stress exceptionally well. Their weld neck design promotes even stress distribution, which helps prevent leaks and maintains the structural integrity of pipelines in medium-pressure applications.

Monel DIN 2633 PN16 WNRF Flange in Philippines, Hastelloy DIN 2633 PN16 Weld Neck Flanges in Manila, Titanium DIN 2633 PN16 Welding Neck Flanges in Davao City, SS DIN 2633 PN16 Weld Neck Flanges Stockist in Cebu City, Nickel Alloy DIN 2633 PN16 Weld Neck Flanges in Puerto Princesa, Inconel DIN 2633 PN16 WNRF Flanges in Baguio, Alloy Steel DIN 2633 PN16 Weld Neck Flanges, Duplex Steel DIN 2631 Weld Neck Flange, Carbon Steel DIN 2633 PN16 Welding Neck Flanges in Philippines.

DIN 2633 PN16 Weld Neck Flanges Specification

Size Chart	1/2″ (15 NB) To 48″ (1200NB)
Coating Flanges Faces	Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint
Design For Size	DIN, EN, ASA, PN, JIS, BS, ANSI, ASME
Pressure Rating Table	Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS
Supporting Flanges Material	Flanges Bolts, Gasket, Ring Joint
Connect Type Type	FF, RTJ, SMF, LMF, RF, LJF
Production Process	Forged, Heat Treated and Machined
Standard	ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange
Machining Equipment	Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc

DIN 2633 PN16 Weld Neck Flanges Dimensions

Germany standard flange DIN 2633 welding neck flanges; nominal pressure 16
Brides à souder à collerette DIN 2633: pression nominale 16
Pipe			Flange				Neck				Raised face		Screws			Weight
																(7,85 Kg/dm3)
Rated	d1		D	b	k	h1	d3	s	r	h2	d4	f	Holes	Thread	d2	Kg
Diameter	ISO Series	DIN Series
15	–	20	95	14	65	35	30	2	4	6	45	2	4	M 12	14	0,648
	21,3	–					32
20	–	25	105	16	75	38	38	2,3	4	6	58	2	4	M 12	14	0,952
	26,9	–					40
25	–	30	115	16	85	38	42	2,6	4	6	68	2	4	M 12	14	1,14
	33,7	–					45
32	–	38	140	16	100	40	52	2,6	6	6	78	2	4	M 16	18	1,69
	42,4	–					56
40	–	44,5	150	16	110	42	60	2,6	6	7	88	3	4	M 16	18	1,86
	48,3	–					64
50	–	57	165	18	125	45	72	2,9	6	8	102	3	4	M 16	18	2,53
	60,3	–					75
65	76,1	–	185	18	145	45	90	2,9	6	10	122	3	4	M 16	18	3,06
80	88,9	–	200	20	160	50	105	3,2	8	10	138	3	8	M 16	18	3,7
100	–	108	220	20	180	52	125	3,6	8	12	158	3	8	M 16	18	4,62
	114,3	–					131
125	–	133	250	22	210	55	150	4	8	12	188	3	8	M 16	18	6,3
	139,7	–					156
150	–	159	285	22	240	55	175	4,5	10	12	212	3	8	M 20	22	7,75
	168,3	–					184
(175)	193,7	–	315	24	270	60	210	5,4	10	12	242	3	8	M 20	22	9,85
200	219,1	–	340	24	295	62	235	5,9	10	16	268	3	12	M 20	22	11
250	–	267	405	26	355	70	285	6,3	12	16	320	3	12	M 24	26	15,6
	273	–					292
300	323,9	–	460	28	410	78	344	7,1	12	16	378	4	12	M 24	26	22
350	355,6	–	520	30	470	82	390	8	12	16	438	4	16	M 24	26	31,2
	–	368														28,8
400	406,4	–	580	32	525	85	445	8	12	16	490	4	16	M 27	30	39,3
	–	419														36,3
(450)	457	–	640	34	585	85	490	8	12	16	550	4	20	M 27	30	44,3
500	508	–	715	34	650	90	548	8	12	16	610	4	20	M 30	33	61
600	610	–	840	36	770	95	652	8,8	12	18	725	5	20	M 33	36	75,4
700	711	–	910	36	840	100	755	8,8	12	18	795	5	24	M 33	36	77
800	813	–	1025	38	950	105	855	10	12	20	900	5	24	M 36	39	101
900	914	–	1125	40	1050	110	955	10	12	20	1000	5	28	M 36	39	122
1000	1016	–	1255	42	1170	120	1058	10	16	22	1115	5	28	M 39	42	162

Largest DIN 2633 PN16 Weld Neck Flanges Supplier in Manila, Philippines

Ting Flanges, a leading supplier in Manila, Philippines, offers an extensive selection of DIN 2633 PN16 Weld Neck Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.

Contact us to get a quick quote for your requirement.

We offer These Flanges as per DIN, ISO, JIS or ANSI Standard.

You’ll find DIN 2633 PN16 Weld Neck Flanges widely used in oil refineries, chemical processing facilities, water treatment plants, and power generation sites. Their sturdy construction and leak-proof welded joints make them perfect for transporting steam, oil, gas, and other fluids under moderate pressure. Additionally, these flanges are utilized in shipbuilding, HVAC systems, and industrial piping networks where reliability and durability are paramount. With their excellent corrosion resistance and mechanical strength, DIN 2633 PN16 Weld Neck Flanges ensure safe, efficient, and long-lasting operation across a variety of industrial settings.

DIN 2633 PN16 Welding Neck Flanges Stockist in Davao City, DIN 2633 PN16 Weld Neck Flanges Supplier in Cebu City, DIN 2633 PN16 Weld Neck Flanges Supplier in Manila, DIN 2633 PN16 Welding Neck Flanges Stockist in Philippines, DIN 2633 PN16 Weld Neck Flanges Manufacturer in MM, DIN 2633 PN16 WNRF Flanges Manufacturer in Philippines.

Types of DIN 2633 PN16 Weld Neck Flanges

Are Custom Sizes Available for DIN 2633 PN16 Weld Neck Flanges?

Yes, we offer custom sizes for DIN 2633 PN16 Weld Neck Flanges to meet specific project needs. Our team at Ting Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@tingflanges.com.

DIN 2633 PN16 Weld Neck Flanges Size Chart

NPS NPS (inch)
NPS NPS (inch)	Diammeter of Flange (inch)	No. of Bolts	Diammeter of Bolts (inch)	Diammeter of Bolt Holes (inch)	Bolt Circle (inch)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Widest Range of DIN 2633 PN16 Weld Neck Flanges in Philippines.

DIN 2633 PN16 Weld Neck Flange Dimensions	Raised Face DIN 2633 PN16 Weld Neck Flange Manufacturer
DIN 2633 PN16 Weld Neck Flange Manufacturer	Flat Face DIN 2633 PN16 Weld Neck Flange Manufacturer
30 inch DIN 2633 PN16 Weld Neck Flange Dealer	Raised Face DIN 2633 PN16 Weld Neck Flanges Manufacturer
DIN 2633 PN16 Weld Neck Pipe Flanges Wholesaler	DIN 2633 PN16 WNRF Flanges Supplier
DIN 2633 PN16 WNRF Flange Stockist in Philippines	Raised Faced DIN 2633 PN16 Slip-On flanges Dealer in Philippines
Raised Face DIN 2633 PN16 Weld Neck Plate Flanges	Titanium DIN 2633 PN16 Welding Neck Flanges
18 inch DIN 2633 PN16 Carbon Steel Weld Neck Flange	DIN 2633 PN16 Weld Neck Flange Dimensions in mm
DIN 2633 PN16 WNRF Flanges Supplier in Manila	Alloy Steel DIN 2633 PN16 Weld Neck Flanges Manufacturer in Philippines
Nickel Alloy DIN 2633 PN16 Welding Neck Flange	Mild Steel DIN 2633 PN16 Weld Neck Flange
Alloy Steel DIN 2633 PN16 Welding Neck Flanges	Copper Nickel DIN 2633 PN16 Weld Neck Flanges at Best Price
DIN 2633 PN16 Welding Neck FF Flange Supplier	Suppliers of DIN 2633 PN16 Weld Neck Flange
DIN 2633 PN16 WNRF Flanges Distributor in Davao City	Flat Face DIN 2633 PN16 Weld Neck Flanges Exporter
DIN 2633 PN16 Welding Neck Flanges Supplier in Cebu City	MS DIN 2633 PN16 Weld Neck Flange
DIN 2633 PN16 Large Diameter Weld Neck Flange	30 Inch DIN 2633 PN16 Weld Neck Pipe Flange Dimensions
8 Inch DIN 2633 PN16 Welding Neck Pipe Flanges	DIN 2633 PN16 Weld Neck Flanges Stockist
Carbon Steel Raised Face DIN 2633 PN16 Weld Neck Flange Stockist	Duplex Steel DIN 2633 PN16 WNRF Flanges Supplier in Manila
ASME SA105N Raised Faced DIN 2633 PN16 Weld Neck Flanges	18 inch Carbon Steel DIN 2633 PN16 Weld Neck Flange
Carbon Steel DIN 2633 PN16 Welding Neck Flange	DIN 2633 PN16 Weld Neck RF Flange Supplier
DIN 2633 PN16 Weld Neck Pipe Flanges Supplier in Puerto Princesa	Duplex Steel DIN 2633 PN16 Weld Neck Flanges
4 inch Stainless Steel DIN 2633 PN16 Weld Neck Flange	DIN 2633 PN16 Weld Neck RF Flanges Stockholder
Stainless Steel DIN 2633 PN16 Weld Neck Flange	ASTM B564 Raised Faced DIN 2633 PN16 Weld Neck Flanges
DIN 2633 PN16 WNRF Flange Exporter	DIN 2633 PN16 Weld Neck Flange Pressure Ratings
German Standard DIN 2633 PN16 Weld Neck Flanges	DIN 2633 PN16 Weld Neck Flange Supplier in Philippines

Material Testing

We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
