Ting Flanges is a reliable manufacturer and supplier of Titanium Blind Flanges based in Manila, Philippines. We pride ourselves on delivering top-notch, corrosion-resistant solutions tailored for industrial pipeline systems. These titanium blind flanges are designed to effectively terminate or isolate sections of piping, ensuring a secure seal in high-performance applications. We offer options in Titanium Grade 2 (commercially pure) and Grade 5 (Ti-6Al-4V), all crafted in line with ASTM, ASME, and ANSI standards. Renowned for their lightweight nature, strength, and outstanding resistance to corrosive environments, our Titanium Blind Flanges are perfect for industries like marine, chemical processing, power generation, and pharmaceuticals.
Titanium Blind Flanges are generally made from either Grade 2 or Grade 5 (Ti-6Al-4V) titanium. Grade 2 is known for its excellent corrosion resistance and moderate strength (~344 MPa), making it suitable for general chemical and marine applications. On the other hand, Grade 5 boasts significantly higher tensile strength (~895 MPa) and improved thermal stability, ideal for more demanding systems. Both grades are lightweight, biocompatible, non-magnetic, and resistant to chloride-induced corrosion and oxidation. Since blind flanges seal off pipe ends, they take advantage of titanium’s superior corrosion resistance, ensuring leak-proof performance and a longer service life even in aggressive and high-temperature environments.
| Trade name | Titanium Blind Flange |
| Titanium Blind Flanges Standard | ASTM B381 / ASME SB381 ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges |
| Titanium Blind Flange Dimensions | B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN |
| Titanium Alloy Blind Flanges Size | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000) |
| Titanium Blind Flanges Class/Pressure |
|
| Flange Face Type | Flat Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
| Gr. 2 Titanium Alloy Blind / Plate Flanges Marking | All Flanges are marked as follows: Grade, Standard, Thickness, Heat No. (Or according to the customer’s request.) |
| Delivery Time | 7-15 working days as usual, It will based on the detailed order quantity. |
Ting Flanges, a leading supplier in Manila, Philippines, offers an extensive selection of Titanium Blind Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Titanium Blind Flanges play a crucial role in terminating or sealing pipe ends, inspection points, or segments for pressure testing in pipelines. They find common use in chemical processing plants, marine settings, desalination systems, and pharmaceutical manufacturing, where corrosion resistance and non-reactivity are vital. In the offshore oil and gas industry, they deliver durable performance even when exposed to seawater. Their use is also on the rise in aerospace and power generation due to their impressive strength-to-weight ratio.
| Element | Titanium | Nitrogen | Carbon | Hydrogen | Iron | Oxygen | Residuals (each) | Residuals (total) |
| % | Balance | 0.03 max | 0.08 max | 0.015 max | 0.30 max | 0.25 max | 0.1 max | 0.4 max |
| 0.2% Proof Stress | Tensile Strength | Elongation | |
| MPa | MPa | % | |
| Annealed | 275-450 | 345 | 20 |
Yes, we offer custom sizes for Titanium Blind Flanges to meet specific project needs. Our team at Ting Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@tingflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
