These flanges are crafted from top-notch carbon steel, stainless steel, or alloy steel, tailored to meet specific operational needs. They boast impressive mechanical properties, with tensile strength ranging from 400 to 700 MPa and yield strength between 200 and 450 MPa. Their exceptional resistance to corrosion, pressure, and thermal stress makes them a reliable choice. The robust design guarantees dimensional stability, a long service life, and consistent performance in high-pressure and high-temperature industrial applications.
Ting Flanges, a leading supplier in Manila, Philippines, offers an extensive selection of EN 1092-1 Type 13 Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
| Size | (1/2″) To (48″) |
|---|---|
| Pressure | PN6, PN10, PN16, PN25, PN40, PN64, PN100, PN160 |
| Size Of Bore Diameter Flange | NPS ≤ 10 |
| Standard Dimensions | EN-1092, ASME B16.48, API605, BS4504, EN1092, UNI, ISO, API7S-43, ANSI/ASME B16.5, API7S-15, MSS S44, IS 2062, ASME B16.36, DIN, AWWA C207, B16.47 Series A & B, BS1560-3.1, ISO70051, API. |
| Minimum Pressure | 150# To 2500# |
| Flange Face Type Manufacturer | Raised Face, Groove And Small Tongue Groove, RTJ, Flat Face, Large Tongue & Large Male-Female And Small Male-Female, Lap-Joint Face. |
| Top Six Type Of Flange | Threaded Flange, Lap Joint Flange, Socket-Weld Flange, Blind Flange, Slip-On Flange, Weld Neck Flange |
| Standard Materials | Duplex Steel & Super Duplex Steel, Copper Nickel, Inconel, Mild Steel, Stainless Steel, Hastelloy, Alloy Steel, Carbon Steel. |
| Thickness Length | NPS ≤ 18 |
| Manufacturing Process | Forged/ Machined/ Heat Treated |
| Other Type Of Flange | Forged/ Plate/ Threaded |
| DN | GAS | Diameters | Thickness | Total | Diameter | Radius | Net | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Outside | bolt | bolt | Bolts | thickness | of the | weight | |||||
| circle | holes | Nr | Type | neck | |||||||
| D | K | L | C2 | H1 | d1 | R1 | Kg | ||||
| 15 | 1/2 | 80 | 55 | 11 | 4 | M10 | 12 | 20 | 30 | 4 | 0,43 |
| 20 | 3/4 | 90 | 65 | 11 | 4 | M10 | 14 | 24 | 40 | 4 | 0,66 |
| 25 | 1 | 100 | 75 | 11 | 4 | M10 | 14 | 24 | 50 | 4 | 0,82 |
| 32 | 1.1/4 | 120 | 90 | 14 | 4 | M12 | 14 | 26 | 60 | 6 | 1,17 |
| 40 | 1.1/2 | 130 | 100 | 14 | 4 | M12 | 14 | 26 | 70 | 6 | 1,4 |
| 50 | 2 | 140 | 110 | 14 | 4 | M12 | 14 | 28 | 80 | 6 | 1,59 |
| 65 | 2.1/2 | 160 | 130 | 14 | 4 | M12 | 14 | 32 | 100 | 6 | 2,17 |
| 80 | 3 | 190 | 150 | 18 | 4 | M16 | 16 | 34 | 110 | 8 | 3,2 |
| 100 | 4 | 210 | 170 | 18 | 4 | M16 | 16 | 40 | 130 | 8 | 3,59 |
| 125 | 5 | 240 | 200 | 18 | 8 | M16 | 18 | 44 | 160 | 8 | 4,94 |
| 150 | 6 | 265 | 225 | 18 | 8 | M16 | 18 | 44 | 185 | 10 | 5,83 |
| Rated Diameter | Flange | Neck | Raised face | Screws | Weight (7,85 Kg/dm3) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d1 | Thread | k | D | b | h1 | d3 | d4 | f | d2 | Thread | Bolt holes | KG | |
| 15 | 21,3 | R 1/2″ | 65 | 95 | 16 | 22 | 35,0 | 45,0 | 2,0 | 14 | M12 | 4 | 0,722 |
| 20 | 26,9 | R 3/4″ | 75 | 105 | 18 | 26 | 45,0 | 58,0 | 2,0 | 14 | M12 | 4 | 1,040 |
| 25 | 33,7 | R 1″ | 85 | 115 | 18 | 28 | 52,0 | 68,0 | 2,0 | 14 | M12 | 4 | 1,250 |
| 32 | 42,4 | R 1-1/4″ | 100 | 140 | 18 | 30 | 60,0 | 78,0 | 2,0 | 18 | M16 | 4 | 1,810 |
| 40 | 48,3 | R 1-1/2″ | 110 | 150 | 18 | 32 | 70,0 | 88,0 | 3,0 | 18 | M16 | 4 | 2,060 |
| 50 | 60,3 | R 2″ | 125 | 165 | 18 | 28 | 84,0 | 102,0 | 3,0 | 18 | M16 | 4 | 2,390 |
| 65 | 76,1 | R 2-1/2″ | 145 | 185 | 18 | 32 | 104,0 | 122,0 | 3,0 | 18 | M16 | 4 | 2,970 |
| 80 | 88,9 | R 3″ | 160 | 200 | 20 | 34 | 118,0 | 138,0 | 3,0 | 18 | M16 | 8 | 3,780 |
| 100 | 114,3 | R 4″ | 180 | 220 | 20 | 40 | 140,0 | 158,0 | 3,0 | 18 | M16 | 8 | 4,380 |
| 125 | 139,7 | R 5″ | 210 | 250 | 22 | 44 | 168,0 | 188,0 | 3,0 | 18 | M16 | 8 | 6,070 |
| 150 | 168,3 | R 6″ | 240 | 285 | 22 | 44 | 195,0 | 212,0 | 3,0 | 22 | M20 | 8 | 7,240 |
EN 1092-1 Type 13 Flanges find extensive use in various industries, including petrochemical, oil and gas, power generation, water treatment, and marine engineering. They are perfect for connecting pipelines, valves, and pumps in systems that require strong, corrosion-resistant joints. Commonly found in refineries, steam plants, and offshore installations, these flanges are celebrated for their superior sealing and pressure-bearing capabilities. With EN 1092-1 Type 13 Flanges, you can count on reliable, leak-free operation and enhanced durability, making them ideal for critical piping systems across diverse industrial settings.
Yes, we offer custom sizes for EN 1092-1 Type 13 Flanges
to meet specific project needs. Our team at Ting Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@tingflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
