Ting Flanges is a reliable manufacturer and supplier of **Hastelloy C276 Flanges** located in **Manila, Philippines**. We take pride in offering top-notch products that are built to withstand the toughest industrial conditions. Our Hastelloy C276 flanges are renowned for their outstanding corrosion resistance and mechanical strength, making them perfect for applications in chemical processing, marine, and power generation sectors. We offer a diverse selection of flange types, including weld neck, slip-on, blind, and threaded flanges, all crafted with precision and in line with international standards. At Ting Flanges, we prioritize dependable performance, durability, and customer satisfaction through cutting-edge manufacturing techniques and rigorous quality control.
Hastelloy C276 Flanges are mainly made up of **nickel, molybdenum, and chromium**, with small amounts of iron, tungsten, and cobalt added to boost their resistance to both oxidizing and reducing agents. They showcase **impressive mechanical properties**, such as high tensile strength (785 MPa), yield strength (355 MPa), and elongation (40%). This alloy holds its integrity even under extreme temperatures and pressures, offering remarkable resistance to pitting, stress-corrosion cracking, and crevice corrosion in harsh chemical and marine environments.
| C276 Forged Fittings Specifications | ASTM B564/ ASME SB564 |
|---|---|
| C276 Alloy Forged Fittings size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Hastelloy C276 Forged Fittings Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Hastelloy C276 Forged Fittings Types | Socketweld Fittings, Screwed-Threaded Fittings |
| ASTM B564 C276 Hastelloy Forged Fittings Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| Hastelloy C276 Forged Fittings Thread | NPT, BSPT, BSPP |
| C276 Hastelloy Forged Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Nickel Alloy C276 Forged Fittings Origin & Mills | Philippines |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Ting Flanges, a leading supplier in Manila, Philippines, offers an extensive selection of Hastelloy C276 Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Hastelloy C276 Flanges are extensively used in industries where corrosion resistance is essential. You’ll find them in **chemical processing plants**, **pharmaceutical equipment**, **marine engineering**, **pollution control systems**, and **power generation units**. These flanges excel in handling **acidic and chloride-laden environments**, such as reactors, heat exchangers, and piping systems. In offshore and desalination facilities, they provide leak-proof, durable connections even in challenging operating conditions. Their ability to endure both oxidizing and reducing media makes them a preferred choice for demanding applications across both **industrial and environmental sectors**.
| ASTM B564 / B564M | Forged Fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Hastelloy Forged Fittings |
| BS21 | Threading. |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| ANSI B16.11 | Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings |
| ANSI/ASME B1.20.1 | Pipe threads, general purpose (inch). |
| ISO 4144 | Hastelloy fittings threaded to ISO 7-1. |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
Yes, we offer custom sizes for Hastelloy C276 Flanges to meet specific project needs. Our team at Ting Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@tingflanges.com.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | OR | GOST |
| Hastelloy C276 | N10276 | 2.4819 | – | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |
| Grade | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V | Ni |
| C276 | 0.01 | 15.0 – 17.0 | 1.0 | 0.08 | 4.00 – 7.00 | 0.04 | 0.03 | 2.5 | 14.5 – 16.5 | 3 – 4.5 | 0.35 | Bal |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | Psi – 1,15,000 , MPa – 790 | 40 % |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
