Ting Flanges, located in Manila, Philippines, stands out as a top manufacturer and supplier of high-quality JIS B2220 10K Flanges, catering to clients in Midland, UK, and around the globe. Renowned for their precision manufacturing and durability, Ting Flanges adheres strictly to Japanese Industrial Standards (JIS), delivering dependable flange solutions for high-pressure and industrial applications. Their JIS B2220 10K Flanges are specifically designed to perform exceptionally well in tough environments. With a strong focus on innovation, quality assurance, and customer satisfaction, Ting Flanges has earned its reputation as a trusted name in the global flange manufacturing scene.
Typically crafted from carbon steel, stainless steel, or alloy steel based on service needs, JIS B2220 10K Flanges boast impressive mechanical properties, featuring tensile strength between 400–700 MPa and yield strength from 200–450 MPa. These flanges are built to withstand high pressure, temperature, and corrosion, ensuring they remain durable and stable in critical piping systems. Their sturdy construction guarantees reliable performance in demanding industrial and marine settings.
Ting Flanges, a leading supplier in Manila, Philippines, offers an extensive selection of JIS B2220 10K Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
| Size | (1/2″) To (48″) |
|---|---|
| Standards | 5K, 10K, 40K, 16K 20K 30K, 63K |
| Size Of Bore Diameter Flange | NPS ≤ 10 |
| Standard Dimensions | EN-1092, ASME B16.48, API605, BS4504, EN1092, UNI, ISO, API7S-43, ANSI/ASME B16.5, API7S-15, MSS S44, IS 2062, ASME B16.36, DIN, AWWA C207, B16.47 Series A & B, BS1560-3.1, ISO70051, API. |
| Minimum Pressure | 150# To 2500# |
| Flange Face Type Manufacturer | Raised Face, Groove And Small Tongue Groove, RTJ, Flat Face, Large Tongue & Large Male-Female And Small Male-Female, Lap-Joint Face. |
| Top Six Type Of Flange | Threaded Flange, Lap Joint Flange, Socket-Weld Flange, Blind Flange, Slip-On Flange, Weld Neck Flange |
| Standard Materials | Duplex Steel & Super Duplex Steel, Copper Nickel, Inconel, Mild Steel, Stainless Steel, Hastelloy, Alloy Steel, Carbon Steel. |
| Thickness Length | NPS ≤ 18 |
| Manufacturing Process | Forged/ Machined/ Heat Treated |
| Other Type Of Flange | Forged/ Plate/ Threaded |
| Nominal | Outside | Inside | Outside | Sectional Dimensions of Flange | Bolt Hole | Nor | Approx. | ||||||||||
| Dia. of | Dia. of | Dia.of | Dia. of | t | T | Dia. of Hub | r | Dia. of | Dia. of | Bolt. | No. | Hole | Bolt | Weight | |||
| Flange | Steel | Flange | Flange | a | b | Face | Rai- sed Face | Circle | of Bolt | Dia. | Size | (kg) | |||||
| Pipe | do | D | f | g | Dia | Holes | h | SOP | BL | SOH | |||||||
| 10 | 17.3 | 17.8 | 90.0 | 12 | – | – | – | – | 1 | 46 | 65 | 4 | 15 | M12 | 0.51 | 0.53 | – |
| 15 | 21.7 | 22.2 | 95.0 | 12 | – | – | – | – | 1 | 51 | 70 | 4 | 15 | M12 | 0.56 | 0.60 | – |
| 20 | 27.2 | 27.7 | 100.0 | 14 | – | – | – | – | 1 | 56 | 75 | 4 | 15 | M12 | 0.72 | 0.79 | – |
| 25 | 34.0 | 34.5 | 125.0 | 14 | – | – | – | – | 1 | 67 | 90 | 4 | 19 | M16 | 1.12 | 1.22 | – |
| 32 | 42.7 | 43.2 | 135.0 | 16 | – | – | – | – | 2 | 76 | 100 | 4 | 19 | M16 | 1.47 | 1.66 | – |
| 40 | 48.6 | 49.1 | 140.0 | 16 | – | – | – | – | 2 | 81 | 105 | 4 | 19 | M16 | 1.55 | 1.79 | – |
| 50 | 60.5 | 61.1 | 155.0 | 16 | – | – | – | – | 2 | 96 | 120 | 4 | 19 | M16 | 1.86 | 2.23 | – |
| 65 | 76.3 | 77.1 | 175.0 | 18 | – | – | – | – | 2 | 116 | 140 | 4 | 19 | M16 | 2.58 | 3.24 | – |
| 80 | 89.1 | 90.0 | 185.0 | 18 | – | – | – | – | 2 | 126 | 150 | 8 | 19 | M16 | 2.58 | 3.48 | – |
| (90) | 101.6 | 102.6 | 195.0 | 18 | – | – | – | – | 2 | 136 | 160 | 8 | 19 | M16 | 2.73 | 3.90 | – |
| 100 | 114.3 | 115.4 | 210.0 | 18 | – | – | – | – | 2 | 151 | 175 | 8 | 19 | M16 | 3.10 | 4.57 | – |
| 125 | 139.6 | 141.2 | 250.0 | 20 | – | – | – | – | 2 | 182 | 210 | 8 | 23 | M20 | 4.73 | 7.18 | – |
| 150 | 165.2 | 166.6 | 280.0 | 22 | – | – | – | – | 2 | 212 | 240 | 8 | 23 | M20 | 6.30 | 10.10 | – |
| (175) | 190.7 | 192.1 | 305.0 | 22 | – | – | – | – | 2 | 237 | 265 | 12 | 23 | M20 | 6.75 | 11.80 | – |
| 200 | 216.3 | 218.0 | 330.0 | 22 | – | – | – | – | 2 | 262 | 290 | 12 | 23 | M20 | 7.46 | 8.00 | – |
| (225) | 241.8 | 243.7 | 350.0 | 22 | – | – | – | – | 2 | 282 | 310 | 12 | 23 | M20 | 7.70 | 15.80 | – |
| 250 | 267.4 | 269.5 | 400.0 | 24 | 36 | 288 | 292 | 6 | 2 | 324 | 355 | 12 | 25 | M22 | 11.80 | 22.60 | 12.70 |
| 300 | 318.5 | 321.0 | 445.0 | 24 | 38 | 340 | 346 | 6 | 3 | 368 | 400 | 16 | 25 | M22 | 12.60 | 27.80 | 13.80 |
| 350 | 355.6 | 358.1 | 490.0 | 26 | 42 | 380 | 386 | 6 | 3 | 413 | 445 | 16 | 25 | M22 | 16.30 | 36.90 | 18.20 |
| 400 | 406.4 | 409.0 | 560.0 | 28 | 44 | 436 | 442 | 6 | 3 | 475 | 510 | 16 | 27 | M24 | 23.20 | 52.10 | 25.80 |
| 450 | 457.2 | 460.0 | 620.0 | 30 | 48 | 496 | 502 | 6 | 3 | 530 | 565 | 20 | 27 | M24 | 29.30 | 68.40 | 33.40 |
| 500 | 508.0 | 511.0 | 675.0 | 30 | 48 | 548 | 554 | 6 | 3 | 585 | 620 | 20 | 27 | M24 | 33.30 | 81.60 | 38.00 |
| (550) | 558.8 | 562.0 | 745.0 | 32(34) | 52 | 604 | 610 | 6 | 3 | 640 | 680 | 20 | 27 | M30 | 42.90 | 105(112) | 49.40 |
| 600 | 609.6 | 613.0 | 795.0 | 32(36) | 52 | 656 | 662 | 6 | 3 | 690 | 730 | 24 | 33 | M30 | 45.40 | 120(134) | 52.60 |
| (650) | 660.4 | 664.0 | 845.0 | 34(38) | 56 | 706 | 712 | 6 | 3 | 740 | 780 | 24 | 33 | M30 | 51.80 | 144(161) | 60.20 |
| 700 | 711.2 | 715.0 | 905.0 | 34(40) | 58 | 762 | 770 | 6 | 3 | 800 | 840 | 24 | 33 | M30 | 59.00 | 176(196) | 70.20 |
| (750) | 762.0 | 766.0 | 970.0 | 36(44) | 62 | 816 | 824 | 6 | 3 | 855 | 900 | 24 | 33 | M30 | 72.80 | 214(248) | 86.50 |
| 800 | 812.8 | 817.0 | 1020.0 | 36(46) | 64 | 868 | 876 | 6 | 3 | 905 | 950 | 28 | |||||
| JIS b2220 Standard | JIS b2220 Class | Diameter Of JIS | Bolt Circle Diameter | No. of Bolts | Size Of Bolt | Bolt Hole Diameter |
|---|---|---|---|---|---|---|
| AS4087 Flanges | PN14 Flanges | 95 | 67 | 4 | M12 | 14 |
| AS 2129 Flange | Table C Flanges | 95 | 67 | 4 | 13 | 14 |
| Table D Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table E Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table F Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table H Flanges | 114 | 83 | 4 | 16 | 17 | |
| Table J Flanges | 114 | 83 | 4 | 16 | 17 | |
| ANSI B16.5 Flanges | ANSI 150 Flanges | 89 | 60 | 4 | 13 | 16 |
| ANSI 300 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 600 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 900 Flanges | 121 | 83 | 4 | 19 | 22 | |
| ANSI 1500 Flanges | 121 | 83 | 4 | 19 | 22 | |
| ISO 7005 (DIN) Flange | PN6 Flanges | 80 | 55 | 4 | M10 | 11 |
| PN10 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN16 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN20 Flanges | 90 | 60.5 | 4 | M14 | 16 | |
| PN25 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN40 Flanges | 95 | 65 | 4 | M12 | 14 |
JIS B2220 10K Flanges find extensive use in industries such as petrochemical, oil and gas, marine, power generation, and water treatment. They are perfect for connecting pipes, valves, and pumps in systems that require high-pressure resistance and leak-proof sealing. These flanges are well-suited for applications involving steam, gas, or fluid transfer, ensuring they deliver long-lasting performance even under varying temperature and pressure conditions. Additionally, JIS B2220 10K Flanges are utilized in refineries, shipbuilding, and industrial plants, providing the strength, precision, and reliability needed for critical pipeline connections.
Yes, we offer custom sizes for JIS B2220 10K Flanges to meet specific project needs. Our team at Ting Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@tingflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
