Ting Flanges is a leading manufacturer and supplier based in Manila, Philippines, specializing in top-notch flange solutions, including Titanium Flat Flanges. These flanges are celebrated for their impressive strength-to-weight ratio, resistance to corrosion, and biocompatibility, making them perfect for use in the chemical, marine, aerospace, and medical sectors. Ting Flanges provides a variety of titanium grades, such as commercially pure titanium (Grade 2) and titanium alloys (like Grade 5), all crafted to meet rigorous international standards. With a strong emphasis on precision engineering, durability, and quick delivery, Ting Flanges ensures dependable titanium flange solutions for both local and global industrial projects.
Titanium Flat Flanges are generally crafted from Grade 2 (CP Titanium) or Grade 5 (Ti-6Al-4V). Grade 2 boasts moderate strength (with a tensile strength of around 344 MPa), outstanding corrosion resistance, and high ductility, making it a great choice for chemical processing. On the other hand, Grade 5 offers significantly higher strength (approximately 900 MPa tensile) while still maintaining good corrosion resistance and moderate weldability. Titanium is non-magnetic, lightweight (about 45% lighter than steel), and resistant to most acids, chlorides, and seawater environments. These characteristics make titanium flat flanges ideal for demanding applications where minimizing weight and withstanding extreme conditions are vital.
| Product Name | Titanium Flat Flanges |
|---|---|
| Size Range | 1/2″ (15 NB) to 48″ (1200NB) |
| Class / Pressure Rating | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Standards / Dimensions | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, BS, GOST, MSS SP-44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605 |
| Titanium Flat Face Flanges / Connection Type | Flat Face Flange (FF), Raised Face Flange (RF), Ring Joint Flange (RTJ), Lap Joint Flange, Male and Female Flange (M&F), Large and Small Tongue-and-Groove Flange (T&G) |
| Dimensions | ANSI B16.5, ANSI B16.47 Series A & B, ASA, API-605, MSS SP44, AWWA, Custom Drawings |
| Custom Design | As per your drawing | AS, BS, ANSI, DIN, JIS | Equal and Reducing Configurations |
| Material Test Certificates (MTC) | As per EN 10204 3.2 and EN 10204 3.1, Test Certificates certifying NACE MR0175, NACE MR0103 |
| Test Certificates | 100% Radiography Test Report, EN 10204/3.1B, Raw Materials Certificate, Third Party Inspection Report, etc |
| Tests | Hydrostatic testing machine, Direct-reading Spectrograph, UI trasonic flaw detector, X-ray detector, Magnetic particle detector |
| Equipment / Machines | Press machine, Pushing Machine, Bending machine, Sand-blasting machine, electric bevelling machine, etc. |
Ting Flanges, a leading supplier in Manila, Philippines, offers an extensive selection of Titanium Flat Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Titanium Flat Flanges find extensive use in industries where corrosion resistance, low weight, and chemical compatibility are crucial. They are commonly utilized in chemical processing plants, desalination units, marine systems, aerospace components, and pharmaceutical manufacturing. Their flat face design is perfect for systems with low-pressure needs and soft gasket materials, ensuring even sealing surfaces. Titanium’s capability to endure aggressive chemicals and chloride-rich environments makes these flanges a reliable choice for challenging applications.
| STANDARD | UNS | WERKSTOFF NR. |
| Titanium Gr 2 | R50400 | 3.7035 |
| Titanium Gr 5 | R56400 | 3.7165 |
| Grade | C | N | O | H | Ti | Fe |
| Titanium Grade 1 | .08 Max | .03 Max | .18 Max | .015 Max | Bal | .20 Max |
| Titanium Grade 4 | .08 Max | .05 Max | .40 Max | .015 Max | Bal | .50 Max |
| Titanium Grade 7 | .08 Max | .03 Max | .25 Max | .015 Max | Bal | .30 Max |
| Titanium Grade 9 | .08 Max | .03 Max | .15 Max | .015 Max | – | .25 Max |
| Titanium Grade 12 | .08 Max | .03 Max | .25 Max | 0.15 Max | – | .30 Max |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 4.5 G/Cm3 | 1665 °C (3030 °F) | Psi – 39900 , MPa – 275 | Psi – 49900 , MPa – 344 | 20 % |
| 4.43 G/Cm3 | 1632 °C (2970 °F) | Psi – 128000 , MPa – 880 | Psi – 138000 , MPa – 950 | 14 % |
Yes, we offer custom sizes for Titanium Flat Flanges to meet specific project needs. Our team at Ting Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@tingflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
